WATER COOLED SUBMERSIBLE MOTORS

[ 50 HZ | 60 HZ ]
PRODUCT RANGE
6″
• 5.5 HP – 60 HP
  (4kW – 45kW)
8″
• 30 HP – 150 HP
  (22kW – 110kW)
7″
• 30 HP – 80 HP
  (22kW – 60kW)
10″
• 100 HP – 250 HP
  (75kW – 185kW)
GENERAL SPECIFICATIONS
  • Water cooled
  • Rewindable motor
  • Vertical and horizontal working
  • NEMA standards
  • Standard voltage 380/460V – 50/60 Hz
  • Suitable for soft starter
  • Ability to operate at different rmp’s with frequency converter (over 30 Hz)
USAGE AREAS
  • Pressurized water supply from borehole drilling
  • Pressurization in industrial applications
  • Water supply to agricultural areas Irrigation systems
  • Irrigation systems
  • Ground water reduction
  • Pressurization
  • Pumping of clean, thin and non-aggressive liquids without fibers or solid particles

TECHNICAL SPECIFICATIONS

Max. Water Temperature: 35°C (optional 70°C)

Max. Sand Content: 50 mg/lt (50 gr/m³

Motor Protection Class: IP68

Max. Operating Sound: 70dB

Max. Water Temperature: 35°C (optional 70°C)

Max. Water Temperature: 35°C (optional 70°C)

Max. Axial Load
• 6″: 25.000N
7″: 37.500N
8″: 45.000N
10″: 75.000N

CATALOG
DRAWING
 PRODUCT SELECTION
PRODUCT CODING
