STAINLESS STEEL SUBMERSIBLE PUMPS
[ 50 HZ | 60 HZ ]
PRODUCT RANGE
4″
• S4CR05C 5 m³/h
• S4CR08D 8 m³/h
• S4CR14E 14 m³/h
7″
• S7CR77E 77 m³/h
• S7CR95F 95 m³/h
8″
• S8CR135G – 135 m³/h
• S8CR160G – 160 m³/h
6″
• S6CR10 L – 10 m³/h
• S6CR17A – 17m³/h
• S6CR24M – 24 m³/h
• S6CR30B – 30 m3/h
• S6CR46C – 46 m³/h
• S6CR60D – 60 m³/h
• S6CR90K – 90 m³/h
10″
• S10CR200I – 200 m³/h
• S10CR250i – 250 m³/h
GENERAL SPECIFICATIONS
- Long-lasting
- High efficiency
- High durability and easy montage
- Easy service and maintenance
- Motor connection in NEMA standard
- Water lubricated bearing with erosion resistant
- Check valve preventing water from escaping back
USAGE AREAS
- Pressurized water supply from borehole drilling
- Pressurization in industrial applications
- Water supply to agricultural areas
- Irrigation Systems
- Ground water reduction
- Pressurization
- Pumping of clean, thin and non-aggressive liquids without fibers or solid particles
ECHNICAL SPECIFICATIONS
Max. Water Temperature: 40°C (optional 70°C)
Max. Sand Content: 50 mg/lt (50 gr/m³)
Motor Protection Class: IP68
Max. Operating Sound: 70dB
Max. Starting Number: 20 (start/h)
Motor Rotation Direction: CC & CCW
Stage and Impeller: Stainless Steel (AISI 304)
Pump Suction and Outlet: Stainless Steel (AISI 304)
Water Capacity: 1– 300m³/h
Max Manometric Head: 700m
CATALOG
DRAWING
PERFORMANCE
PRODUCT SELECTION
PRODUCT CODING
