OIL COOLED SUBMERSIBLE MOTORS
[ 50 HZ | 60 HZ ]
PRODUCT RANGE
4″
• Monofaze
1HP – 3HP
(0,75kW – 2,2kW)
• Trifaze
1HP – 10HP
(0,75kW – 7,5kW)
6″
• Trifaze
5,5HP – 30HP
(4kW – 22kW)
GENERAL SPECIFICATIONS
- Oil cooled
- Rewindable motor
- Vertical and horizontal working
- NEMA standards
- Standard voltage 380/460V – 50/60 Hz
- Maximum water temperature: 35 ° C
- Motor protection class: IP68
USAGE AREAS
- Pressurized water supply from borehole drilling
- Pressurization in industrial applications
- Water supply to agricultural areas
- Irrigation Systems
- Ground water reduction
- Pressurization
- Pumping of clean, thin and non-aggressive liquids without fibers or solid particles
TECHNICAL SPECIFICATIONS
Max. Water Temperature: 35°C (optional 70°C)
Max. Sand Content: 50 mg/lt (50 gr/m³)
Motor Protection Class: IP68
Max. Operating Sound: 70dB
Max. Starting Number: 20 (start/h)
Motor Rotation Direction: CC & CCW
Max. Axial Load:
• 4″: 1 HP – 1.500 N
• 1,5 HP – 4 HP 2.500 N
• 5,5 HP – 10 5.000 N
• 6″: 5,5 HP – 30 HP 10.000 N
