NORYL VERTICAL MULTISTAGE PUMPS
[ 50 HZ | 60 HZ ]
PRODUCT RANGE
55 HSE
• 1 m³/h-4 m³/h
59 HSF
• 4 m³/h-9 m³/h
624 HSM
• 4 m³/h-18 m³/h
49 HSD
• 2 m³/h-7 m³/h
618 HSL
• 4 m³/h-16 m³/h
636 HSE
• 10 m³/h-30 m³ / h
GENERAL SPECIFICATIONS
-
Used in multi-storey buildings, industry, gardens, parks and farms
-
Shaft: Stainless steel
-
Stage and Impeller: Noryl
-
Booster Unit`s Lower and Upper Interconnector: Cast Iron
- Because of the mechanical seal, no need to maintenance
-
Quiet and Smooth Running
-
Easy to install, low operating cost
-
Easy service and maintenance
USAGE AREAS
- Pressurized water supply from borehole drilling
- Pressurization in industrial applications
- Water supply to agricultural areas
- Irrigation Systems
- Ground water reduction
- Pressurization
- Pumping of clean, thin and non-aggressive liquids without fibers or solid particles
TECHNICAL SPECIFICATIONS
Max. Starting Number: 100 (start/h) for 1HP-5,5 HP, 20 (start/h) for above 5,5HP
Motor Power: 1-2HP (Monophase), 3-30HP (Threephase)
Water Temperature: 0- 40°C
Max. Voltage: 380 V (+-%5V)220 V (+-%5V)
Vertical Multistage Pump System = VMS Pump + Conrol Pump + Expansion Tank + Assembling Parts
CATALOG
DRAWING
PERFORMANCE
PRODUCT SELECTION
PRODUCT CODING
