NORYL SUBMERSIBLE PUMPS

[ 50 HZ | 60 HZ ]
PRODUCT RANGE
6″
• S6 L-3.6 m³/h-16.2 m³/h
6″
• S6 H-7.2 m³/h-43.2 m³/h
6″
• S6 M-3.6 m³/h-21.6 m³/h
6″
• S6 P-18 m³/h-61.2 m³/h
GENERAL SPECIFICATIONS
  • Long-lasting
  • High efficiency
  • High durability and easy montage
  • Easy service and maintenance
  • Motor connection in NEMA standard
  • Water lubricated bearing with erosion resistant
  • Check valve preventing water from escaping back.

USAGE AREAS

  • Pressurized water supply from borehole drilling
  • Pressurization in industrial applications
  • Water supply to agricultural areas
  • Irrigation Systems
  • Ground water reduction
  • Pressurization
  • Pumping of clean, thin and non-aggressive liquids without fibres or solid particles

TECHNICAL SPECIFICATIONS

Max. Water Temperature: 40°C

Max. Sand Content: 25 mg/lt (25 gr/m³)

Motor Protection Class: IP68

Max. Operating Sound: 70dB

Max. Starting Number: 20 (start/h)

Motor Rotation Direction: CC & CCW

Stage and Impeller: Noryl

Pump Suction and Outlet: Casting

Water Capacity: 3,6– 61,2m³/h

Max Manometric Head: 400m

Shaft: Stainless Steel (AISI 420)

Outlet Diameter: 2,5” – 3”

CATALOG
DRAWING
PERFORMANCE
PRODUCT SELECTION
 PRODUCT CODING
