IN-LINE STAINLESS STEEL VERTICAL MULTISTAGE PUMPS
[ 50 HZ | 60 HZ ]
PRODUCT RANGE
5 HCR
• 2 m³/h-7 m³/h
15 HCR
• 11 m³/h-23 m³/h
32 HCR
• 16 m³/h-36 m³/h
64 HCR
• 30 m³/h-80 m³/h
10 HCR
• 6 m³/h-13 m³/h
20 HCR
• 12 m³/h-29 m³/h
45 HCR
• 25 m³/h-55 m³/h
90 HCR
• 50 m³/h-110 m³/h
GENERAL SPECIFICATIONS
- Used in multi-storey buildings, industry, gardens, parks and farms.
- Hydrophore shaft: Stainless Steel
- Stage and Impeller: Noryl
- Booster Unit`s Lower and Upper Interconnector: Cast Iron
- Because of the mechanical seal, no need to maintenance
- Quiet and Smooth Running
- Easy to install, low operating cost.
- Easy service and maintenance.
USAGE AREAS
- Pressurized water supply from borehole drilling
- Pressurization in industrial applications
- Water supply to agricultural areas
- Irrigation Systems
- Ground water reduction
- Pumping of clean, thin and non-aggressive liquids without fibers or solid particles
TECHNICAL SPECIFICATIONS
Max. Starting Number: 100 (start/h) for 1HP -5,5 HP, 20 (start/h) for above 5,5HP
Motor Power: 1-2HP (Monophase), 3-30HP (Threephase)
Water Temperature: 0- 40°C
Max. Voltage: 380 V (+-%5V)220 V (+-%5V)
Vertical Multistage Pump System = VMS Pump + Conrol Pump + Expansion Tank + Assembling Parts
CATALOG
DRAWING
PERFORMANCE
PRODUCT SELECTION
PRODUCT CODING
