CAST IRON SUBMERSIBLE PUMPS

[ 50 HZ | 60 HZ ]
PRODUCT RANGE
5″
• S5A-14.4 – 36 m³/h
7″
• S7A-54.0 – 126 m³/h
8″
• S8A-72 – 144 m³/h
• S8B-90 – 162 m³/h
• S8D-90 – 198 m³/h
6″
• S6B-25.2 – 44.8 m³/h
• S6A-28.8 – 54.0 m³/h
• S6D-32.4 – 64.8 m³/h
• S6E-36.0 – 97.2 m³/h
• S6F-36.0 – 126 m³/h
10″
• S10A-144 – 270 m³/h
• S10B-150 – 400 m³/h
GENERAL SPECIFICATIONS
  • Long-lasting
  • High efficiency
  • High durability and easy montage
  • Easy service and maintenance
  • Motor connection in NEMA standard
  • Water lubricated bearing with erosion resistant
  • Check valve preventing water from escaping back.
USAGE AREAS
  • Pressurized water supply from borehole drilling
  •  Pressurization in industrial applications
  • Water supply to agricultural areas
  • Irrigation Systems
  • Ground water reduction
  • Pressurization
  • Pumping of clean, thin and non-aggressive liquids without fibers or solid particles

TECHNICAL SPECIFICATIONS

Max. Water Temperature: 40°C (optional 70°C)

Max. Sand Content: 50 mg/lt (50 gr/m³)

Motor Protection Class: IP68

Max. Operating Sound: 70dB

Max. Starting Number: 20 (start/h)

Motor Rotation Direction: CC & CCW

Stage and Impeller: Cast IronGG 25 (optional Bronz)

Max. Capacity: 500m³/h

Max Manometric Head: 360m

CATALOG
DRAWING
PERFORMANCE
PRODUCT SELECTION
PRODUCT CODING
